SPECIFICATIONS

Brand Name: BADODOSECURITY

Certification: CE

Direction: None

Hign-concerned Chemical: None

Model Number: 8001

Origin: Mainland China

Security Mode: Fail Safe

Smart home platform: None

1.Single button can finish all the control command(such as close, open, stop)
2.Can delete any remote control separately
3.Can adjust the working time of motor
4.Can program the time of auto close
5.Can set auto close when restored power after power off
6.With infrared detection connecto

7.  this board is normally open board and it needs use NO limit switch(magnetic limit switch NO version)

1 for magnetic limit switch input

2 for motor wire input

3 for power input

4 for adjusting the torque force

5 for for adjusting closing force

6 dip switch for multi function setup

7 is learning button to program remote control(press learn button, then press any key of remote control two times to add remote controls)

8 is testing button to test the motor;

9 for change the motor running direction

10 for flashing lamp input

11 is remote control receiver

12 for photocell, manual button, keypad and gsm input

LPSECURITY MANUAL Push button Switch for barrier gates and gate openers/Commercial Garage Door Opener Three Button StationUSD 4.49/piece LPSECURITY 433MHZ Wireless Wall Keypad for garage/swing/sliding gate opener/wireless keypad switch with receiverUSD 27.99/pack 12VDC 24VDC OUTDOOR WATERPROOF Electric Lock drop bolt for Automatic Swing Gate DOOR Opener OperatorUSD 38.50/piece LPSECURITY garage sliding swing gate motor flashing lamp bulb blinker safety alarm light strobe lamp(no sound)USD 7.99/piece LPSECURITY with UK EU AU US 12VDC adapter 200 users GSM gate motor opener pump Remote Control switchUSD 19.98-40.98/piece LPSECURITY sliding gate motor gate galvanized steel gear rail rack 1m per pcUSD 7.00/piece nylon gear rack rail for auto sliding gate opener 1 m per pcUSD 6.00/piece This control board is desinged for sliding gate motors, power input 220V; not for swing gate opener;   remote control optional and no battery included; this board not compatible with other remote control;and this board is 220V AC motor, not for other voltages; manual is not coming with this product and please leave us the email and we will send you the manual by email;
